  • ELGI EN 05, 7.5 HP Rotary Screw Air Compressor offering 24 CFM @ 125 PSI | 208-230/460 Volt, 3-Phase

ELGI EN 05, 7.5 HP Rotary Screw Air Compressor offering 24 CFM @ 125 PSI | 208-230/460 Volt, 3-Phase

7.5 HP Rotary Screw Air Compressor | 208-230/460 Volt, 3-Phase | EN 05
Model:
EN 05
Vendor Item Number:
S013425
Order by Phone
Call Any of our Sales Experts to Place an Order. We offer Expert Advice, Quick Quotes and Product Availability.
Our Team Consists of "Air Compressor Experts", Challenge Us!
Mon-Fri 8 am to 5:00 pm EST
Call Toll Free:  866-203-9939



"Over 100 Years of Experience"
Request a Quote
Ships Direct
Rating:
100% of 100
4  Reviews
Write a Review
  • DESCRIPTION
  • TECH DATA
  • PRODUCT REVIEWS
  • VIDEOS
  • Product Q & A

DESCRIPTION

ELGI EN Series Air Compressors have the BEST Warranty in it's class.
3-40 HP Base Mounted Air Compressors

TECH DATA

  • Product Specification

    • Capacity (CFM) @ 100/125 PSI
      24 CFM @ 100 PSI
    • Cooling Type
      Air Cooled
    • Horsepower (HP)
      7.5 HP
    • Pressure Rating
      max 175 PSI
    • Pump Drive
      Belt
    • Rated Duty Cycle
      100%

  • Overview & Technical Details

    • Body Size
      Base Mounted
    • Power Source/Type
      Electric
    • Sound Level dBA
      64 dB(A)

  • Dimensions & Weight

    • Dimensions (L)(W)(H)
      18.1" x 23.6" x 50.2"
    • Height (inch)
      33.3"
    • Length (inch)
      24.2"
    • Width (inch)
      28.1"
    • Weight (lbs)
      423.000000

  • Motor Data

    • Motor Type
      TEFC

  • Power Requirements

    • 208/3/60
      24.2 Full Load Running Amps
    • 230/240/3/60
      22 Full Load Running Amps
    • 460/480/3/60
      11 Full Load Running Amps
    • Standard Voltages
      208-230-460/3/60

  • Warranty

    • Standard Warranty
      1 Year Parts & Labor, 6 Year Airend Warranty
